    Airport Security Flap Barrier Turnstile Swing Gate Face Recognition Parking Qr Code

    Ask Lasest Price
    Brand Name : Zento
    Model Number : ZT-948A
    Certification : CE ISO9001 ROHS
    Price : Negotiable
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 100 pcs per week
    Delivery Time : 3-7days
    • Product Details
    • Company Profile

    Airport Security Flap Barrier Turnstile Swing Gate Face Recognition Parking Qr Code

    Flap Turnstile Airport Security Swing Gate Face Recognition Parking Barrier Qr Code


    Flap turnstile is a high-tech product for intelligent management of personnel channel. It is an upgraded product of tripod turnstile and swing turnstile. The product has exquisite workmanship, fully functional, and classic design. It is mainly used in high-end places such as high-grade residential areas, intelligent buildings, hotels, subways, docks, clubs, gyms and so on. The equipment organically integrates mechanical, electronic, microprocessor control and various identification technologies, which is convenient to be compatible with the use of card reading and identification equipment such as IC card, ID card, bar code and fingerprint.


    Product Advantages


    1. Problem-self-checking function.

    2. Arm Turning: Bi-direction

    3. When power off, arm open automatically and power on again, arm will be held automatically.

    4. When valid card read and passenger passed, arm can be delayed to close from 1-60s which can be set in the control panel.

    5. Auto-reposition function: After card read, passenger doesn't pass within regulated time, turnstile will cancel order automatically. And the regulated time can be set by managers.

    6. Anti-rush function: if there is no open signal, arm will be holding tightly.

    7. Stable running with little noise.

    (1) Automatic return function: After the passage process is completed, the brake wings automatically return to the initial blocking position.

    (2) Power-off and opening function : When the power is off, the system will automatically open the brake wings to open, which is convenient for evacuation of the crowd and meets fire protection requirements.

    (3) Anti-illegal intrusion function: When the card is invalid, there is no card swiping, or the passage is forbidden, the forcible entry into the channel will be regarded as illegal intrusion, and the system will automatically alarm and close the flap.

    (4) Anti-reverse intrusion function: Before the end of the passage process in a certain direction, pedestrians entering the passage from the opposite direction will be regarded as reverse intrusion, the system will automatically alarm and close the wing.

    (5) Anti-trailing function: The photoelectric switch detects the pedestrian traffic situation, and detects the following phenomenon (the people behind are close to the person in front, intending to pass without swiping the card), the system will automatically alarm and close the brake wings.

    (6) Intelligent linkage alarm: including illegal intrusion, reverse traffic and other alarms, which can be linked with other alarm monitoring equipment and can be heard.

    (7) Anti-pinching and anti-collision function:
    A. Infrared anti-pinch: Install multiple pairs of photoelectric switches near the area where the wing is active (anti-pinch area). Once a person or object is detected in the anti-pinch area, the wing automatically stops; The flaps continued to move.
    Housing Material
    Stainless Steel 304
    Production Process
    CNC Laser Cutting
    Telescopic flap length
    250mm
    Passage width
    ≤ 600 MM
    Power input
    AC 220V/110V ±10% 50/60MHZ (optional)
    Operation voltage
    DC24V, 3A, Power: 40W( Servo Motor Optional)
    Communication Interface
    RS232
    Passage direction
    Single directional/Bi-directional(Optional)
    Flow rate
    35-45 people/miunute
    Automatic Reset Function
    Automatically locked within set time(Time Adjustable)
    LED Indcator
    Yes
    Operation Humidity
    ≤90%RH
    Operation Temperature
    -25℃~+75℃
    Operation Eenvironment
    Indoor,Outdoor(Shelter)
    Protection Funcetion
    Encoder limit,Clutch anti-collision,Infrared anti-pinch,Break-inalarm fifiunction

    Packaging & Shipping
    1. Normally, we offer UPS/DHL/FEDEX/TNT express with door to door service if the G.W. of goods is less than 50Kg. You just need to pay some custom clearance charge for receiving the items at your specific address. The shipping date is about 3-5 days.
    2. If G.W. is over 80Kg, we will check if air shipment is more economical than express. Shipping by air you need to go to the airport to take items. If you are not very familiar with these works, you may need a broker to help you deal with the customs clearance and goods transportation. The air shipping is about 2-7 days.
    3. If you make a large order, we suggest that you ship by sea. We have our own forwarder for the shipment service.
