Maintenance Free Access Control Flap Barrier Gate Visitor System
Self-detect Door
The outline of the product is formed after pressing the stainless
steel plate. The shape is featured as a pleasing appearance, a good
looking, stainless and durable. The system is provided with a
standard electric interface and is easily integrated into the
product with read/write facilities. A special control system is
equipped in the product to meet the requirement of fire control, so
that the smooth passage flow is ensured, realizing a timely
diverting of passengers. The product is featured as stable in
performance, safe and reliable, and can be used widely in the
places where passenger flow is great and monitoring is needed such
as stations, harbors and guest house.
Main Functions and Features of the System
1) Rapid identification technique, available to identify accurately
and efficiently the magnetic card, bar code card, ID card and IC
card.
2) DC Brushless Motor, Maintenance Free
3) On-line or off –line mode(optional)
4) Real time trouble self-detect and alarm indication, ensuring system
safe operation and facilitating maintenance and operation
5) With direction indication, guiding passenger to entry and exit.
6) Self automatic locking to prevent forcedly passing without the card
7) Automatic counting and displaying number of passenger, facilitating
observation and with a displaying total amount as high as 90,000
8) Light and sound alarm indication function, preventing illegal entry
or irregular passing
9) Powerful on-line intelligent control mode, facilitating you:
A)To adjust the operation speed of the barrier according to the flow
of passenger and improve the passing rate.
B)To set up operation mode for passage entry and exit.
C)To read card with multiple times, the special function meeting the
application requirements of a particular site.
D)To set up the card reading with or without memory.
E)To select a reasonable normally open or close mode, to divert the
flow of passengers effectively.
F) Setting function humanized for reset of over time passing.
10)The infrared sensing technique realizes real time monitor of
passage, safe protection and tail-proof.
12) The processing mode in emergency or in special conditions.
13) Having standard input/output port, facilitating the integration
of the system and the other equipment, to realize far end control management.
14) Super combination capability, with the combined application of
products of different passage types and series, not affecting the
system performance.
15) Strong system expending capability, available to add new
product at any time
16) Far end control management: function to far end control of barrier
mode, meeting the special requirements of the users and the fire
protection
17) Resetting automatically. After reading card, if the passer didn’t
pass at set time, the system will cancel pass permission
automatically, the administrator can set the passing time by
himself.
Main Technical Specifications
| Dimension | 1400*300*980mm |
| Material | SS304,thickness is no less than 1.5mm |
| Tickness | Head: 2.0mm |
| Input Voltage | AC220±10%,50HZ |
| Driving motor | 24V |
| Failure-free operation | 5 million/time |
| Weight | 35kg |
| Traffic speed | Normally open-50persons/min; Normally closed-50persons/min |
| Flap Opening/Closing Time | 0.4S adjustable |
| Channel width | ≤600mm |
| Infrared sensor | 4 pairs |
| Operating temperature | -30ºC-70ºC |
| Communication interface | RS485/TCP/IP |
| Manufacturing Technique | CNC laser cutting |
Occasion Application:
Suitable for commercial buildings, Schools, GYM fitness centers or
clubs, subways, airports, therm parts, Supermarket, Train stations,
Library, exhibition halls, Government buildings, financial
institutions, clubs, and other high-end Places related to entrance
access control solutions.
